Led Display

Led Display
Led Display
Product Code : (UHI-SMDP10mm)
Brand Name : UH LED INDIA INC.
Trade Information
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
  • Payment Terms
  • Cash in Advance (CID), Cheque, Letter of Credit (L/C), Telegraphic Transfer (T/T), Others
  • Delivery Time
  • 40 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • Wooden boxes & Customized .
  • Main Domestic Market
  • All India
  • Certifications
  • ISO
Product Description

We are engaged in offering a wide range of UHI-SMDP10mm Led Display that has excellent visual, clear and exquisite effect. Its flatness is good. It has no color cast when look from different angles. It is easy to assembly, install and transport with simple packing and convenient use. It is made in consultant with supreme technician and is know for its long life. Our clients can avail these products at most leading prices.

Function :

  • Excellent visual effect, clear and exquisite
  • Good flatness
  • Easy to clean ,welding spots inoxidable
  • Closer look available, better effects without glare and mosaic
  • Good viewing angle
  • Easy to assembly, install and transport with simple packing and convenient use
  • Vivid mixed colors
  • No color cast when look from different angles
  • Excellent heat-sinking, high stability ,no scrapped lamp

Application :

advertising LED display, shopping mall LED display for logo showing , bank & stock exchange LED display for rates showing , train & bus station , airport , telecommunication LED screen system for information showing and instruction , Stage performances and so on.

Technical Specification :

Indoor SMD 3in1 full color display---10mm

module parameters

Pixel Pitch

10mm

Led Configuration

1R1PG1B(SMD3528)

Size

160mm X 160mm

Pixel Configuration

16(horizontal) X 16(vertical)

cabinet parameters

Size

640mm X 640mm X 135/85mm

Area

0.4096m2/cabinet

Metal Housing

steal with zinc painting

Pixel Density By Area

10000pixels/sq meter

Pixel Density By Per Module

4096dots per module

Panel Weight

20kg/panel

Lose Control Rate/Blind Spot Ratio

less than 0.03%,the discrete distribution

Modules(Horizontal)

4

Modules(Vertical)

4

screen parameters

Brightness

1800cdm2

Viewing Distance

>10m

Viewing Angle(50% Brightness)

hor.120o ver,120o

Life Time

100,000hour (50% brightness)

Operating Temperature

-20oC+60oC

Operating Humidity

10%85%

Operation Voltage

AC220V+10% / AC380V+10%, 50hertz+10%

Power Consumption(Typical)

MAX 700W/m2(400W/m2)

Front Color

black, rubber

Protection

IP65

PC control system & software of
led studio

Communication Distance

<100meters (by cat5 net cable), 500meters of multi-mode optical fiber;1000meters of single-mode optical fiber

Brightness Adjustment

Manual or Auto 100 Grade Adjustable

Grey Scale

10 Bit/Color

Color Temperature

Typical 6500k, 5000--9000k Be Adjustable

Color

256 X 256 X 256

Led Driving Method

1/8 Static Scan; Constant Current Drive

Frame Rate

60 Hertz

Image Refresh Rate

300 Hertz; Max100hz

Input Signal

HDTV/PAL/S-VIDEO/VGA
